Heart Rhythm Monitor

The ​Ticker ® Model TCR201 provides heart rhythm monitoring ECG signal.

Easy BNC connector hookup to oscilloscope enables true ECG display.

​

Now featuring the TCR301 Model.

Model TCR201
*New*
Model TCR301

Note

The Ticker model TCR201 is used for research and evaluation by experimenters who wish to study ECG waveforms

Note



Connect electrode's cables to the Ticker®

  • Black cable connector to RL

  • Red cable connector to RH

  • Yellow cable connector to LH

01

Connect BNC cable to signal connector of the Ticker® and to the oscilloscope

02

Connections to the body

  • Place the electrodes provided in the box* on your body (See image for locations)

  • RL to the right leg

  • RH to the right hand

  • LH to the left hand

* You can use an alternative any standard gel electrodes

03

Turn the Ticker® switch ON

04

You can now observe your ECG rhythm signals on the oscilloscope screen.

05

Instructions
